AEM Cloud. SAML configuration not working in Preview Tier

[SaitoYoshio]

Hi All,

I'm configuring SAML 2.0 for Publish in AEM as a Cloud Service.

However, SAML is not working as expected in the Preview tier.

Where is the problem?

I am referring to the following documentation:

https://experienceleague.adobe.com/en/docs/experience-manager-learn/cloud-service/authentication/sam...

The Publish tier is working as expected.

After authenticating with the IdP, users are redirected to /saml_login on Publish:

publish-xxxx.adobeaemcloud.com/saml_login

During the saml_login process, a "login-token" cookie is issued, and users can then view the website.

On the Preview tier, users are also redirected to the IdP, and after authenticating, they are redirected to /saml_login on Preview:

preview-xxxx.adobeaemcloud.com/saml_login

However, no "login token" cookies are issued, and the user is redirected back to the IdP URL again.

/saml_login → IdP Login → /saml_login → IdP Login → (infinite loop)

• "login-token" cookie is not issued on the Preview tier.

• This results in an infinite loop.

Where is the problem?

To identify the cause, I tried changing several settings.

The difference between the Publish and Preview configurations is controlled by environment variables,

so I tried intentionally using an incorrect value for the Preview tier’s "idpCertAlias."

However, the result remained an infinite loop with no noticeable change.

Normally, if "idpCertAlias" is set to an incorrect value, an invalid_token error should occur.

This suggests that on the Preview tier, the certificate might not be referenced at all, leading to the infinite loop.

I followed the setup guide and steps to use Package Manager to replicate the global trust store to the Publish tier, but am I correct in assuming this applies to the Preview tier as well?

Thanks,

Saito.

[SwetaB]

Hi @SaitoYoshio ,

I hope you are using keystorepassword property. If yes then specify “useEncryption” : false in your configuration. This solved it for me. Also can you check the saml logs.

[SaitoYoshio]

@SwetaB

Thanks for Reply.

The useEncryption property in the com.adobe.granite.auth.saml.SamlAuthenticationHandler~...cfg.json file is

"useEncryption": false,

[SaitoYoshio]

Hi ALL

In my case, SAML on the Publish tier is working fine.

SAML on the Preview tier is not working.

I think this is because the Trust Store is not applied to the Preview tier.

I have written a new ticket.

Please tell me the correct way to set up the SAML IdP Certificate File on the Publish Tier and Preview Tier.

https://experienceleaguecommunities.adobe.com/t5/adobe-experience-manager/i-want-to-know-how-to-set-...

Thanks,

Saito.

[SaitoYoshio]

Report on the current situation
I deployed the .p12 file under /etc/truststore to the Preview Tier using the pipeline, but got a different error.

(The infinite loop does not occur.)

ERROR MESSAGE on Browser

--------------

Unexpected Error: Looks like we are having some issues with our service. We are working hard to bring it online again.

 --------------

When I checked the error.log, I found the following output:

--------------

java.lang.SecurityException: javax.jcr.PathNotFoundException: keystorePassword not found on /etc/truststore

--------------

Thank you.

Saito.

[Uppari_Ramesh]

@SaitoYoshio I had faced similar issue earlier,

Basically Adobe created a SamlAuthenticationHandler custo ath handler and if you see code inside, you will be needed proper SAML response code from issuer. Whatever the response we got will validated against the installed cert. Just check your SAML response is proper or not.

1. Try reinstalling idp smal cert in trustore again and copy the new alias ID and paste in  osgi config. Use the cert which is issued to preview-xxxx.adobeaemcloud.com domain only but not publish.

2. Also check if users are creating in AEM with Random uuids.

[SaitoYoshio]

hi @Uppari_Ramesh

Thank you for your reply.

Publish and Preview register different certificate files, and the alias name refers to different files.

The URL of the SAML response is also exclusive to Preview.

> 2. Also check if users are creating in AEM with Random uuids.

I don't understand what this means.

When creating a user, do I need to create it with Random uuid?

Thanks

Saito.

[Uppari_Ramesh]

Hi @SaitoYoshio ,

When I got the similar issues as yours, users were creating with uuids instead of user emails so just wanted to check.

Have you tried reinstalling the cert? Also share the exception you are getting in error log

Thanks,

Ramesh.

[SaitoYoshio]

Hi @Uppari_Ramesh

The certificate should be correct if you reinstall it.
The error log currently occurring is as follows:

18.07.2025 06:38:59.656 [cm-pxxxx-exxxx-prev-aem-publish-xxxx-jwxwg] *WARN* [qtp1288958285-68] org.apache.sling.auth.core.AuthUtil isRedirectValid: Redirect target must not be empty or null

18.07.2025 06:39:54.627 [cm-pxxxx-exxxx-prev-aem-publish-xxxx-jwxwg] *ERROR* [qtp1288958285-65] org.apache.felix.http Exception while processing request to /content/saml_login

java.lang.SecurityException: javax.jcr.PathNotFoundException: keystorePassword not found on /etc/truststore

at com.adobe.granite.keystore.internal.KeyStoreServiceImpl.extractStorePassword(KeyStoreServiceImpl.java:626) [com.adobe.granite.crypto.keystore:4.0.10]

......Continued

I would appreciate any advice you can give me.

Thanks,

Saito.

[Uppari_Ramesh]

@SaitoYoshio  The log says keystore password not present at /etc/truststore path.

1. Have you validated the crypto encoded value in the property keystorePassword in below path:
2. The property keystorePassword contains crypto encoded trustore password. Check if this property is available.
3. If not available you need to delete existing trustore and then you need to create new one. Beware that deleting trustore will get more problem if you had any other certs in it before.

[SaitoYoshio]

I was able to solve this problem.
I reported the solution in the latest comment.

Thank you for your help.

Saito

[SaitoYoshio · Accepted solution]

The issue with this ticket has been resolved.

The root of the problem is that the IdP certificate installed on Author cannot be replicated to the Preview environment.

The guidance for setting up SAML describes the procedure for replicating with Package Manager, but this method only replicates to the Publish environment, so it is not possible to set up the Preview environment.

https://experienceleague.adobe.com/en/docs/experience-manager-learn/cloud-service/authentication/sam...

There seem to be two ways to replicate the /etc/truststore node to the Preview environment.

We were able to resolve the issue using the latter method, which uses the Distribution tool.

Method 1: Replicate to Preview with a custom workflow

https://experienceleague.adobe.com/en/docs/experience-manager-cloud-service/content/operations/repli...

・Set the parameter "agentId" to "preview".

・This setting allows you to replicate to the Preview environment.

Method 2: Replicate to Preview using the Distribution tool.

・Open Author > Tools > Deployment > Distribution.

・On the Distribution management screen, select Preview.

・Select the Distribute tab, select Action = Add node, Path Browser = /etc/truststore, and Submit.

Thank you for your cooperation.

Saito
