MediaHandler renditions red tint

  • May 29, 2025
  • 4 replies
  • 508 views

Hello,



I'm facing an issue where images have red tint on the renditions, while the original image is totally fine.



We're using AEM 6.5 with SP 6.5.21.0 and renditions are generated using MediaHandler from package https://wcm.io/media-handler.

What I've manage to figure out is that when the images size is bigger, for example over 2-3 MBs, the renditions have red tint, but after compressing the image, then it's fine.

The main issue here is that this is happening only on one environment, while the others are totally fine, even with the bigger images.



Any ideas what could be the issue here? I've added a new logger for that package with DEBUG level, but no indicators, as well nothing in the error.log.



Could there be some heap space issue, or is there any OSGi config doing some limitation on asset storage size / renditions? Currently our storage contains about ~40GB of assets.



Thanks in advance.



Example of an invalid picture:







This post is no longer active and is closed to new replies. Need help? Start a new post to ask your question.

4 replies

SantoshSai
Community Advisor
SantoshSaiCommunity Advisor
Community Advisor
May 29, 2025

Hi @matijaleskovic,

Since the originals are fine and smaller versions work without a problem, it definitely points to something environment-specific.

A few things you might want to try:

1. Check the Java setup

Run java -version on the environment where it’s failing and compare it with a working one. Sometimes different Java vendors or versions (like OpenJDK vs Oracle JDK) can behave differently when it comes to image rendering.

2. Look into memory settings

It's worth taking a look at your heap size and other memory settings (-Xmx, -Xms) in that environment. If it’s running low on memory during image processing, it might not crash, but could produce weird results like this red tint. Try increasing the heap size a bit and see if that helps.

3. Make sure Java isn’t running in headless mode (just for testing)

If the environment is using -Djava.awt.headless=true, try temporarily disabling it by setting it to false and see if that changes anything. Sometimes headless mode messes with image rendering, especially with certain color profiles.

4. Enable a bit more logging

You already added DEBUG for the media handler, which is great. You can also try turning on logs for:

  • javax.imageio

  • com.sun.imageio.plugins

That might give more clues if something is silently failing during rendition generation.

Hope that helps!

Santosh Sai
    arunpatidar
    Community Advisor
    arunpatidarCommunity Advisor
    Community Advisor
    May 30, 2025

    Hi @matijaleskovic

    Can you check if you have quality configurations?

    https://github.com/wcm-io/io.wcm.handler.media/blob/5414b1a44cfa350cf93d39c297c7bb7d0f977a2e/src/main/java/io/wcm/handler/mediasource/dam/impl/dynamicmedia/DynamicMediaSupportServiceImpl.java#L108

    Arun Patidar
      AmitVishwakarma
      Community Advisor
      AmitVishwakarmaCommunity Advisor
      Community Advisor
      May 30, 2025

      Hi @matijaleskovic ,



      Since the issue is environment-specific and size-dependent, probable causes are:

        - Java ImageIO color profile issue (often with CMYK JPEGs)

        - Java vendor/version inconsistencies

        - headless mode affecting rendering

        - Low memory or heap pressure during image conversion

        - Missing or corrupted imageio plugins or fonts

        - Incorrect or missing quality or MediaHandler config

      1. Check Java Version and Vendor

      On both environments:

      java -version

      In headless mode, several image rendering libraries exhibit improper behavior, particularly when handling color profiles (such as CMYK > RGB conversions).



      3. Raise Memory & Heap Configurations

      Large file image conversion may be silently failing because of memory pressure, even if the server in question doesn't crash.

      Verify the current Xmx, Xms, and XX:MaxPermSize flags, and if they are low, raise them.
      For instance:

      -Xms2g -Xmx4g



      Patch the Quality Settings (MediaHandler Configuration)

      Verify your MediaHandler OSGi parameters, paying particular attention to the quality and format options.

      Configuration example:

      mediahandler.asset.autoRendition.quality = 0.85

      Use the OSGi Console to configure this: http://localhost:4502/system/console/configMgr/io.wcm.handler.media.impl.asset.RenditionHandlerImpl

      Channel corruption or red tints may occur if the quality is too poor or if the preset compression is not successful.



      5. Install the ImageIO plugins that are missing.

      Java's ImageIO may malfunction silently and provide distorted renditions if huge files contain CMYK profiles and your server is not compatible.

      Use the most reliable option, the TwelveMonkeys ImageIO plugin:

        - JARs can be downloaded at https://github.com/haraldk/TwelveMonkeys.

        - Place these in /crx-quickstart/install/ or use the OSGi bundle to deploy.

        - Restart AEM

      Modules required:

      imageio-core imageio-jpeg imageio-tiff imageio-metadata

      This adds support for CMYK JPEGs and advanced profiles.



      6. Enable Verbose ImageIO Logging

      Add to AEM start command or set via sling.properties:

      -Djava.util.logging.config.file=/path/to/logging.properties

      Sample logging.properties:

      handlers= java.util.logging.ConsoleHandler java.util.logging.ConsoleHandler.level = FINE javax.imageio.level = FINE com.sun.imageio.plugins.level = FINE

      7. Compare the Original and Compressed Versions

      Since the problem is fixed by compression, try:

      Reduce the original's resolution or convert it to sRGB.

      Compare renditions in both contexts after re-uploading.

      The red tint is probably caused by a failed color profile interpretation if the original was CMYK with an ICC profile.


      8. Examine the X11 packages and typeface (Linux only)

      If your AEM is Linux-based and renders using graphical libraries or fonts, compare:

      fc-list dpkg -l | grep font

      Ensure all image/font rendering packages are installed.

      Regards,
      Amit



      kautuk_sahni
      Community Manager
      kautuk_sahniCommunity Manager
      Community Manager
      June 23, 2025

      @matijaleskovic Did you find the suggestions helpful? If you need more information, please let us know. If a response resolved your issue, kindly mark it as correct to help others in the future. Alternatively, if you discovered a solution on your own, we'd appreciate it if you could share it with the community. Thank you.

      Kautuk Sahni
